The Schneider Electric Acti9 iC60H A9F84325 is a three-pole miniature circuit breaker designed for low-voltage distribution systems. It is rated at 25 A with a C-type thermal-magnetic trip curve, providing reliable protection against overloads and short circuits in circuits with moderate inrush currents. The device offers a short-circuit breaking capacity of 30 kA at 220–240 V AC under EN/IEC 60947-2 and 10,000 A at 400 V AC under EN/IEC 60898-1, while also supporting DC applications up to 180 V. It complies with both industrial and residential standards. Key features include the VisiTrip indicator for quick fault location and the VisiSafe green strip for confirming physical contact opening. Its fast-closing mechanism, independent of the toggle, extends service life to 10,000 electrical and 20,000 mechanical cycles. The breaker has a 500 V AC rated insulation and Class 3 limitation, which helps reduce downstream protection costs. It mounts on a 35 mm DIN rail, occupies six 9 mm pitches (54 mm width), and measures 85 × 54 × 78.5 mm with a net weight of 0.375 kg. It provides IP20 terminal protection, operates from -35 °C to +70 °C, and comes in white (RAL9003). With pollution degree 3, overvoltage category IV, and a 54% recyclability potential, it is a durable and sustainable choice for three-phase circuits.
