Parameter | Details |
Product Model | A9F94440 |
Range | Acti9 |
Product Name | Acti9 iC60 |
Product or Component Type | Miniature circuit-breaker (MCB) |
Device Short Name | iC60L |
Device Application | Distribution |
Poles Description | 4P |
Number of Protected Poles | 4 |
[In] Rated Current | 40 A |
Network Type | AC / DC |
Trip Unit Technology | Thermal-magnetic |
Curve Code | C |
Magnetic Tripping Limit | 8 x In ± 20% |
Utilisation Category | Category A conforming to EN/IEC 60947-2 |
Suitability for Isolation | Yes conforming to EN/IEC 60947-2; Yes conforming to EN/IEC 60898-1 |
Standards | EN/IEC 60947-2, EN/IEC 60898-1 |
Breaking Capacity (Icu) – EN/IEC 60947-2 (AC) | 70 kA at 12…133 V AC 50/60 Hz; 50 kA at 220…240 V AC 50/60 Hz; >25 kA at 380…415 V AC 50/60 Hz; >20 kA at 440 V AC 50/60 Hz |
Breaking Capacity (Icu) – EN/IEC 60947-2 (DC) | >20 kA at ≤180 V DC |
Breaking Capacity (Icu) – EN/IEC 60898-1 (AC) | >15,000 A at 400 V AC 50/60 Hz |
Service Breaking Capacity (Ics) – EN/IEC 60947-2 (AC) | 35 kA (50% x Icu) at 12…133 V AC 50/60 Hz; >25 kA (50% x Icu) at 220…240 V AC 50/60 Hz; >12.5 kA (50% x Icu) at 380…415 V AC 50/60 Hz; >10 kA (50% x Icu) at 440 V AC 50/60 Hz |
Service Breaking Capacity (Ics) – EN/IEC 60947-2 (DC) | >20 kA (100% x Icu) at ≤180 V DC |
Limitation Class | 3 conforming to EN/IEC 60898-1 |
Rated Operational Voltage (Ue) | 12…133 V AC 50/60 Hz; 220…240 V AC 50/60 Hz; 380…415 V AC 50/60 Hz; 440 V AC 50/60 Hz; ≤180 V DC |
Rated Insulation Voltage (Ui) | 500 V AC 50/60 Hz conforming to EN/IEC 60947-2 |
Rated Impulse Withstand Voltage (Uimp) | 6 kV conforming to EN/IEC 60947-2 |
Network Frequency | 50/60 Hz |
Contact Position Indicator | Yes |
Control Type | Toggle |
Local Signalling | Trip indicator |
Mounting Mode | Clip-on; Removable comb busbar installed |
Mounting Support | 35 mm DIN rail |
Comb Busbar and Distribution Block Compatibility | Top or bottom: Yes |
Connection Pitch | 18 mm between phases |
Number of 9 mm Pitches | 8 |
Height | 85 mm |
Width | 72 mm |
Depth | 78.5 mm |
Net Weight | 0.5 kg |
Colour | White |
Mechanical Durability | 20,000 cycles |
Electrical Durability | 10,000 cycles |
Connections – Terminals | Single terminal (top or bottom), for 1 cable(s), 1…35 mm², rigid, copper; 3.0 cable(s), 16 mm², rigid, copper, with accessory; 1.0 cable(s), 50 mm², rigid, aluminium, with accessory; 1.0 cable(s), 1…25 mm², flexible, copper; 1.0 cable(s), 25 mm², flexible with ferrule, copper; 1.0 cable(s), flexible, copper or aluminium, with ring terminal and accessory; 3 cable(s), 10 mm², flexible, copper, with accessory |
Wire Stripping Length | 14 mm for top or bottom connection |
Tightening Torque | 3.5 N·m top or bottom |
Earth-leakage Protection | Separate block |
IP Degree of Protection | IP20 conforming to IEC 60529; IP40 in modular enclosure (Insulation class II) conforming to IEC 60529 |
Pollution Degree | 3 conforming to EN/IEC 60947-2 |
Overvoltage Category | IV |
Tropicalisation | 2 conforming to IEC 60068-1 |
Relative Humidity | 95% at 55 °C |
Operating Altitude | 0…2000 m |
Ambient Air Temperature for Operation | -35…70 °C |
Ambient Air Temperature for Storage | -40…85 °C |
Packing Units – Package 1 (PCE) | 1 pc; H 7.500 cm × W 7.200 cm × L 9.500 cm; weight 493.000 g |
Packing Units – Package 2 (BB1) | 3 units; H 8.000 cm × W 9.800 cm × L 22.500 cm; weight 1.537 kg |
Packing Units – Package 3 (S03) | 33 units; H 30.000 cm × W 30.000 cm × L 40.000 cm; weight 17.394 kg |
Country of Origin | FR |
Warranty | 18 months |
Carbon Footprint – Total | 63 kg CO₂ eq. |
Carbon Footprint – Manufacturing (A1-A3) | 3 kg CO₂ eq. |
Carbon Footprint – Distribution (A4) | 0.1 kg CO₂ eq. |
Carbon Footprint – Installation (A5) | 0 kg CO₂ eq. |
Carbon Footprint – Use Phase (B2, B3, B4, B6) | 58 kg CO₂ eq. |
Carbon Footprint – End-of-life (C1-C4) | 1 kg CO₂ eq. |
Environmental Disclosure | Product Environmental Profile |
Packaging with Recycled Cardboard | Yes |
Packaging without Single-use Plastic | Yes |
SCIP Number | 26F71d1-98cf-4280-8725-455b9a6b2fb9 |
EU RoHS Directive | Compliant |
REACH Regulation | Reference contains Substances of Very High Concern above the threshold |
OECD PFAS Regulation | Item contains PFAS Chemicals |
POP Directive | No POPs |
Halogen-free Status | Product contains halogen above thresholds |
PVC Free | Yes |
Silicone-free | Yes |
Recyclability Potential | 54% |
End-of-life Manual Availability | No need of specific recycling operations |
Take-back | No |
WEEE Label | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
