330102-00-20-10-02-00 Armored Proximity Probe

  • Bently Nevada

  • 330102-00-20-10-02-00

  • In Stock

  • T/T

  • Xiamen

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
snapchat sharing button
telegram sharing button
sharethis sharing button

330102-00-20-10-02-00 is an armored eddy current probe from the Bently Nevada 3300 XL series, with a total length of 1.0 meter (3.3 feet). This model builds on the base configuration of the 330101 (3/8-24 UNF threads, 0.0‑inch unthreaded length, 2.0‑inch case length, standard ClickLoc connector) by adding stainless steel armor to the cable, providing excellent crush resistance, tensile strength, and abrasion protection. It does not include connector protectors or hazardous area approvals. The armor consists of a flexible stainless steel braid with an FEP outer jacket, suitable for harsh industrial environments where mechanical damage is a concern.

With a total length of 1.0 m, this probe is typically used with a 4.0‑meter extension cable (e.g., 330130-040-00-00) and a 5‑meter Proximitor Sensor (e.g., 330180-50-00) to form a complete 5‑meter system (1.0 m probe + 4.0 m extension cable = 5 m system). This configuration is ideal for installations where the Proximitor Sensor is mounted close to the equipment (e.g., in a junction box) and the cable requires additional mechanical protection.

Model Breakdown: 330102-00-20-10-02-00 Configuration Details

Following Bently Nevada’s part number coding system (refer to datasheet Pages 13-15), the fields in this model number represent the following:

Field

Code

Parameter

Description

Base Model

330102

3300 XL 8 mm Probe, 3/8-24 UNF thread, with armor

Compatible with 3300 XL 8 mm and 3300 5 mm systems

Unthreaded Length (A)

00

0.0 inches

Distance from probe tip to start of thread; shortest configuration

Overall Case Length (B)

20

2.0 inches

Total threaded length (code 20 = 2.0 inches)

Total Length Option (C)

10

1.0 meter (3.3 ft)

Total probe cable length (including connector)

Connector & Cable Option (D)

02

Miniature coaxial ClickLoc connector, standard cable

Standard FEP‑insulated cable (with armor), gold‑plated ClickLoc connector

Agency Approval (E)

00

Not required

Standard industrial version for non‑hazardous areas

Key Configuration Note: The defining features of this model are armor and a 2.0‑inch case length. Armor provides mechanical protection for applications where crushing, pulling, or abrasion risks exist. The 2.0‑inch case length is suitable for moderately deep mounting holes. The 1.0 m total length is for 5‑meter systems (paired with a 4.0 m extension cable). The unthreaded length is 0.0 inches, meaning the thread starts immediately after the probe tip. This model does not include connector protectors or hazardous area approvals.

Armor Details

Stainless Steel Armor

The armor layer consists of flexible AISI 302 or 304 stainless steel braid, covered with an FEP outer jacket, providing the following protection:

  • Crush Resistance: Prevents cable damage from compression during installation or operation

  • Tensile Strength: Enhances overall cable pull strength for conduit routing

  • Abrasion Resistance: Prevents insulation damage from friction against metal conduits or equipment edges

  • Cut Resistance: Protects internal conductors from accidental cuts or sharp object damage

No Connector Protector

This model does not include pre-installed connector protectors, so the connector is exposed to the environment without additional oil or dust sealing. It is suitable for dry, clean environments where the connector will not contact turbine oil, moisture, or dust. If environmental sealing is required, select a version with connector protectors (e.g., 330102-00-20-10-03-00 or 330102-00-20-10-12-00, etc.).

Selection Tip: Armored cable weighs approximately 103 g/m (standard cable is 34 g/m). Consider the tensile load on connectors and probes during installation. The minimum bend radius for armored cable is 25.4 mm (1.0 in), the same as standard cable, but the armor increases stiffness.

Application Scenarios & Selection Guide

330102-00-20-10-02-00 is suitable for the following typical applications:

  1. 5‑Meter System + Mechanical Protection: Paired with a 4.0 m extension cable (e.g., 330130-040-00-00) and a 5 m Proximitor Sensor (e.g., 330180-50-00) to form a complete 5‑meter monitoring system, with armor providing additional mechanical protection.

  2. Installations Requiring Moderate Thread Engagement and Armor: The 2.0‑inch case length (approx. 50.8 mm) is suitable for moderately deep mounting holes where cable protection is needed, such as near compressors, steam turbines, generators, and other equipment where vibration, friction, or accidental impact may occur.

  3. Conduit Routing (Dry Environments): When cables must be routed through metal conduit or cable trays and connector sealing is not required, armor effectively protects the cable against sharp edges at conduit ends.

  4. High Mechanical Stress Environments (No Oil Exposure): Near large rotating machinery, cables may be subject to crushing or abrasion; armor provides a safety margin while the connector remains in a relatively clean area.

  5. Standard Industrial Environments: No hazardous area approvals – suitable for non‑hazardous, dry, clean installations.

Selection Notes:

  • Total Length Matching: Probe length + extension cable length = Proximitor Sensor total system length (5 m or 9 m). This 1.0 m probe must be used with a 4.0 m extension cable to form a 5‑meter system.

  • Case Length Selection: The 2.0‑inch case is suitable for moderate depth mounting holes. If the mounting hole is shallow, select an armored model with a 0.8, 1.2, 1.4, or 1.6‑inch case; if the hole is very deep, consider 3.0, 4.0, or 6.0‑inch cases. Important: The datasheet maximum recommended thread engagement is 0.563 inches – use lock nuts and washers to limit actual engagement to ≤0.563 inches.

  • Armored Cable Bend Radius: While the minimum bend radius is 25.4 mm, armor increases cable stiffness; allow sufficient clearance when routing.

  • Weight: Armored cable weighs approx. 103 g/m; consider the tensile load on connectors and probes during long runs.

  • Connector Protection: If the environment has oil mist or moisture, select a version with connector protectors (e.g., 330102-00-20-10-03-00).

  • Ambient Temperature: Standard probe is rated to +177°C. For higher temperatures, select an ETR high‑temperature armored probe (330192 series).

  • Hazardous Area Requirements: If explosive gas atmospheres are present, select the version with hazardous area approvals (e.g., 330102-00-20-10-02-05).

Mechanical Dimensions & Installation

  • Probe Tip Diameter: 8.0 mm (0.31 in)

  • Thread Specification: 3/8-24 UNF-2A; recommended lock nut torque: 11.2 N·m (100 in·lbf)

  • Overall Case Length: 2.0 in (50.8 mm)

  • Unthreaded Length: 0.0 in

  • Cable Outer Diameter: Armored section 7.67 mm (0.302 in) maximum; armor ferrule 10.2 mm (0.40 in) maximum; non‑armored section (near connector) 3.68 mm (0.145 in)

  • Connector Outer Diameter: 7.24 mm (0.285 in) maximum

  • Minimum Bend Radius: 25.4 mm (1.0 in)

  • Installation Tips: Before installation, measure the effective thread depth of the mounting hole. Use lock nuts and washers to limit engagement to ≤0.563 inches. The armored section can withstand higher pulling forces, but it is still recommended to attach pulling lines to the cable jacket rather than the connector. Set the probe gap to the recommended -9 Vdc (approx. 1.27 mm), monitored via the Proximitor Sensor output voltage.

Related Products & Compatible Configurations

This probe is typically used with the following products:

Companion Product

Recommended Model

Description

Extension Cable

330130-040-00-00

4.0 m standard cable, forms 5 m system

Proximitor Sensor

330180-50-00

5 m system panel‑mount Proximitor, no approvals

Lock Nut

04301007

3/8-24 lock nut with safety wire holes

Mounting Bracket

137492-01

Aluminum threaded mounting bracket, 3/8-24 thread

For other configurations, refer to the following armored probe options:

Model

Thread

Unthreaded Length

Case Length

Total Length

Armor

Protector

Approvals

Application

330102-00-20-10-02-00

3/8-24

0.0"

2.0"

1.0 m

Yes

No

None

Current model, 5 m system, armored, long case

330102-00-20-10-03-00

3/8-24

0.0"

2.0"

1.0 m

Yes

Yes

None

Armored version with connector protector

330102-00-20-10-02-05

3/8-24

0.0"

2.0"

1.0 m

Yes

No

ATEX/IECEx

Hazardous area armored version

330101-00-20-10-02-00

3/8-24

0.0"

2.0"

1.0 m

No

No

None

Non‑armored standard version

330102-00-20-05-02-00

3/8-24

0.0"

2.0"

0.5 m

Yes

No

None

9 m system short probe, armored, long case

Matching Extension Cable: This probe must be used with a 4.0‑meter extension cable (e.g., 330130-040-00-00) to form a complete 5‑meter system.

Inquiry & Technical Support

330102-00-20-10-02-00 is a commonly used armored probe model in the Bently Nevada product line, designed for 5‑meter systems requiring mechanical protection. For pricing, lead time, or technical drawings, please contact us:

  • Online Inquiry: Click the “Request a Quote” button and provide the model number for a prompt response.

  • Technical Support: If you need assistance verifying whether this configuration meets your installation dimension and mechanical protection requirements, please describe your installation environment (conduit routing, oil exposure, vibration levels, etc.) and we will help recommend the optimal configuration.

Specification

Value

Probe Tip Diameter

8.0 mm (0.31 in)

Thread Specification

3/8-24 UNF-2A

Unthreaded Length

0.0 in (0 mm)

Overall Case Length

2.0 in (50.8 mm)

Total Length (including cable)

1.0 meter (3.3 ft)

Cable Type

75Ω triaxial, FEP insulation, with stainless steel armor

Armor Material

Flexible AISI 302 or 304 stainless steel, FEP outer jacket

Armor Outer Diameter

7.67 mm (0.302 in) maximum

Armor Ferrule Outer Diameter

10.2 mm (0.40 in) maximum

Connector Type

Miniature coaxial ClickLoc gold‑plated connector (male)

Connector Protector

None (for protector, select models with 02/03/12/13 options)

Linear Range

2 mm (80 mils), from approx. 0.25 mm (10 mils) to 2.3 mm (90 mils)

Output Voltage Range

Approx. -1 Vdc to -17 Vdc (over linear range)

Recommended Radial Vibration Gap Voltage

-9 Vdc [approx. 1.27 mm (50 mils)]

Incremental Scale Factor (ISF)

7.87 V/mm (200 mV/mil) ± 5% (including interchangeability error, 0°C to +45°C)

Deviation from Straight Line (DSL)

< ±0.025 mm (±1 mil) (0°C to +45°C, 1 m system)

Temperature Range (Probe)

-52°C to +177°C (-62°F to +350°F)

Probe Tip Material

Polyphenylene sulfide (PPS)

Probe Case Material

AISI 303 or 304 stainless steel

Minimum Target Diameter

15.2 mm (0.6 in) flat target

Minimum Recommended Shaft Diameter

76.2 mm (3 in) (for radial vibration)

Frequency Response

0 to 10 kHz, +0, -3 dB (with up to 305 m of field wiring)

Tensile Strength

Probe case to cable: 330 N (75 lbf) maximum rated

330102
